Microservices Testing Strategies: An Ultimate Guide

Last Updated on Sep 5, 2024

Key Takeaways

For microservices, formulating an effective testing strategy is a challenging task. A Combination of Testing Strategies with right tools that provide support at each layer of testing is a key.
Post integration of the service, the risk of failures and cost of correction is high. So a good testing strategy is required.
Tools like Wiremock, Goreplay, Hikaku, VCR, Mountebank, and many others are used for microservices testing purposes.
For the effective approach, there should be a clear Consensus on the test strategy. Required amount of testing should be focused at the correct time with suitable tools.
For the microservices architecture, there is a scope of unit testing, integration testing, component testing, contract testing, and end to end testing. So the team must utilise these phases properly as per the requirements.

In today’s time, software development companies prefer to use the latest approaches for application development, and using microservices architecture is one such initiative. Developers use microservices architecture and divide functional units of the application that can work as individual processes. These singular functions can easily address user traffic and still remain lightweight. But they need to be frequently updated to scale up the application. Besides this, the developers also have to carry out microservices testing strategies to make sure that the application is performing the way it is expected to.

Let’s first understand what types of challenges developers are facing while using a microservices architecture.

1. Challenges in Microservices Testing

Microservices and monolithic architectures have many differences. It also comes with some challenges that every developer should know before testing microservices.

Challenge	Description
Complexity	Though single services are very simple, the entire microservices system is a bit complex which means that to work with the developers one needs to be careful in choosing and configuring the databases and services in the system. Even testing and deploying each service can be challenging as this is a distributed nature.
Data Integrity	Microservices offer distributed databases which are problematic for data integrity as business applications might require updates with time, but here database upgrade becomes compulsory. This is the case when there is no data consistency. So, testing becomes more difficult.
Distributed Networks	Microservices can be deployed on various servers with different geographical locations by adding latency and making the application know about network disruptions.In this case, when tests rely on the network, it will fail if there is any fault in the code and this will interrupt the CI/CD pipeline.
Test Area	Every microservice usually points to many API endpoints which means that testable surfaces increase and developers have to work on more areas which is a bit time-consuming task.
Multiple frameworks used for development	Though the developers choose the best-suited microservices frameworks and programming languages for each microservice when the system is big, it becomes difficult to find a single test framework that can work for all the components.
Autonomous	The app development team can deploy microservices anytime but the only thing they need to take care of is that the API compatibility doesn’t break.
Development	Microservices can be independently deployable, so extra checks are required to ensure they function well.Even the boundaries need to be set correctly for microservices to run perfectly fine.

2. Microservices Testing Strategy: For Individual Testing Phases

Now let us understand the testing pyramid of microservices architecture. This testing pyramid is developed for automated microservices testing. It includes five components.

The main purpose of using these five stages in microservices testing is:

Testing Type	Key Purpose
Unit Testing	To test various parts (class, methods, ) of the microservice.
Contract Testing	To test API compatibility.
Integration Testing	To test the communication between microservices, third-party services, and databases.
Component Testing	To test the subsystem’s behavior.
End-to-End Testing	To test the entire system.

2.1 Unit Testing

The very first stage of testing is unit testing. It is mainly used to verify the function’s correctness against any specification. It checks a single class or a set of classes that are closely coupled in a system. The unit test that is carried out either runs with the use of the actual objects that are able to interact with the unit or with the use of the test doubles or mocks.

Basically, in unit tests, even the smallest piece of the software solution is tested to check whether it behaves the way it is expected to or not. These tests are run at the class level. Besides this, in unit testing one can see a difference in whether the test is performed on an isolated unit or not. The tests carried out in this type of testing method are written by developers with the use of regular coding tools, the only difference is in its types as shown below.

Solitary Unit Testing:

Solitary unit tests ensure that the methods of a class are tested.
It mainly focuses on the test result to always be deterministic.
In this type of unit testing, collaborations and interactions between an object of the application and its dependencies are also checked.
For external dependencies, mocking or stubbing to isolate the code is used.

Sociable Unit Testing:

These tests are allowed to call other services.
These tests are not deterministic, but they provide good results when they pass.

Basically, as we saw here, unit tests when used alone do not offer a guarantee of the system’s behavior. The reason behind it is that in unit testing, the core testing of each module is covered but it doesn’t cover the modules when they are in collaborative mode. Therefore, in such cases, to make sure that the unit tests are run successfully, developers make use of test doubles and ensure that each module works correctly.

2.2 Integration Testing

The second stage of microservices testing is Integration tests. This type of testing is used when the developer needs to check the communication between two or more services. Integration tests are specially designed to check error paths and the basic success of the services over a network boundary.

In any software solution, there are different components that interact with one another as they may functionally depend on each other. Here, the integration test will be used to verify the communication paths between those components and find out any interface defects. All the test modules are integrated with each other and they are tested as a subsystem to check the communication paths in this testing method.

There can be three types of communications that happen in the microservices architecture:

Between two different microservices
Between Microservice and third-party application
Between Microservice and Database

The aim of integration testing is to check the modules and verify if their interaction with external components is successful and safe. While carrying out such tests, sometimes it becomes difficult to trigger the external component’s abnormal behavior like slow response time or timeout. In such cases, special tests are written by the developers to make sure that the test can respond as expected.

Basically, integration tests come with the goal of providing assurance that the coding schema matches the stored data.

2.3 Component Testing

Component tests are popular when it comes to checking the full function of a single microservice. When this type of testing is carried out, if there are any calls made by the code to the external services, they are mocked.

Basically, a component is a coherent, well-encapsulated, and independently replaceable part of any software solution. But when it comes to a microservice architecture, these component tests become a service. This means that developers perform component tests in microservices architecture to isolate any component’s complex behavior.

Besides this, component tests are more thorough in comparison to integration testing as it has the capability to travel on all the paths. For instance, here we can know how the component responds to the network’s malformed requests. This process can be divided into two parts.

In-process Component Testing

Test runners exist in the same process or thread as microservices.
Microservices can be started in an offline test mode.
This testing works only with single-component microservices.

Out-process Component Testing

Appropriate for any size of components.
Components here are deployed unaltered in a test environment.
All dependencies in microservices are stubbed or mocked out.

2.4 Contract Testing

This testing type is carried out when two microservices gather via an interface and they need a bond to specify all the possible transactions with their data structures. Here, even the possible side effects of the inputs and outputs are analyzed to make sure that there is no security breach in the future. This type of testing can be run by the client, the producer, or both.

Consumer-side

The downstream team writes and executes the tests.
The testing method connects microservices in a mocked version of the producer service.
Microservices are checked to see if they can consume client-side API.

Producer-side

Producer-side contract tests run in upstream services. .
Clients’ API requests are checked along with the producer’s contract details.

2.5 End-to-End Testing

The last type of testing in our list is End-to-End Testing. This approach is used for testing microservices completely. This means that end-to-end testing checks the entire microservices application. It checks whether the system meets the client’s requirements and helps in achieving the goal. When this test is carried out by the developers, it doesn’t bother about the internal architecture of the application but just verifies that the system offers a business goal. In this case, when the software is deployed, it is treated as a black box before getting tested.

Besides this, as end-to-end testing is more about business logic, it checks the proxies, firewall, and load balancer of the application because generally they are affected by the public interference from API and GUIs. In addition to this, end-to-end testing also helps developers to check all the interactions and gaps that are present in microservice-based applications. This means that testing microservices applications completely can be possible with end-to-end testing.

Now, let’s look at various scenarios and how these phases can apply.

3. Microservices Testing Strategies for Various Scenarios

Here we will go through various microservices testing strategies for different scenarios to understand the process in a better way.

Scenario 1: Testing Internal Microservices Present in the Application

This is the most commonly used strategy to test microservices. Let’s understand this with an example.

For instance, there is a social media application that has two services like

Selecting Photos and Videos
Posting Photos and Videos

Both services are interconnected with each other as there is close interaction between them in order to complete an event.

Testing Scopes	Description
Unit Testing	For each individual microservice, there is a scope of unit testing. We can use frameworks like JUnit or NUnit for testing purposes. First, one needs to test the functional logic. Apart from that, internal data changes need to be verified. For Example: If Selecting Photos and Videos Service returns a selectionID then the same needs to be verified within the service.
Integration Testing	Both the microservices are internally connected in our case. In order to complete an event, both need to be executed in a perfect manner. So, there is a scope for Integration testing.
Contract Testing	It is recommended to use testing tools that enable user-driven contract testing.Tools like Pacto, Pact, and Janus are recommended.In this testing, data passed between services needs to be validated and verified. For the same, one can use tools like SOAPUI.
End-to-End Testing	End to End Testing, commonly referred to as E2E testing, ensures that the dependency between microservices is tested at least in one flow. For example, an event like making a post on the app should trigger both the services i.e. Selecting Photos and Videos and Posting Photos and Videos.

Scenario 2: Testing Internal Microservices and Third-party Services

Let’s look at the scenario where third-party APIs are integrated with Microservices.

For Example, in a registration service, direct registration through the Gmail option is integrated. Here registration is modelled as a microservice and interacts with gmail API that is exposed for authenticating the user.

Testing Scopes	Descriptions
Unit Testing	The developers can perform unit tests to check the changes that happened internally. Frameworks like xUnit are used to check the functional logic of the application after the change. The TDD approach can also be considered whenever possible.
Contract Testing	The expectations from the consumer’s microservices are checked which decouples itself from the external API. Test doubles can be created here using Mountebank or Mockito to define Gmail API.
Integration Testing	Integration tests are carried out if the third-party developers offer sandbox API.This type of testing checks whether the data is being passed perfectly from one service to another and to see if the services are integrated as required.
End-to-End Testing	With end-to-end testing, the development team ensures that there are no failures in the workflow of the system. One checks the dependencies between the microservices and ensures that all the functions of the application are working correctly.

Scenario 3: Testing Microservices that are Available in Public Domain

Let’s consider an e-commerce application example where users can check the items’ availability by calling a web API.

Testing Scopes	Descriptions
Unit Testing	Here, the development team can carry out unit testing to check all functions of the application that the services have defined. This testing helps to check that all the functions of the services work perfectly fine as per the user’s requirements. It also ensures that the data persistence is taken care of.
Contract Testing	This testing is essential in such cases. It makes sure that the clients are aware of the contracts and have agreed upon them before availing of the facilities provided by the application. Here, the owner’s contracts are validated, and later consumer-driven contracts are tested.
End-to-end Testing	Here we can test the workflow using End-to-end Testing. It enables software testing teams to make sure that the developed application offers facilities as per the requirement. End-to-end testing also ensures that the integration of services with external dependencies is secured.

4. Microservices Testing Tools

Here are some of the most popular Microservices testing tools available in the market.

Wiremock: It is a very popular simulator that is used by developers when they want to do integration tests. Unlike any other general-purpose mocking tool, Wiremock has the capability to work by developing an actual HTTP server that the code that is being tested can connect to as a real web service.
Goreplay: It is an open-source tool for network monitoring. It helps in recording live traffic of the application and this is why it is used by the developers to capture and replay live HTTP traffic.
Mountebank: It is a widely used open-source tool that enables software development companies to carry out cross-platform and multi-platform test doubles over the wire. With the help of Mountebank, the developers can simply replace the actual dependencies of the application and test them in the traditional manner.
Hikaku: It is a very popular test environment for microservices architecture. It helps the developers to ensure that the implementation of REST-API in the application actually meets its specifications.
VCR: Developers use the VCR tool to record the tests that they carry out on the suite’s HTTP interactions. This recording can be later played for future tests to get accurate, fast, and reliable test results.

5. Conclusion

Microservices testing plays a very important role when it comes to modern software development tactics. It enables developers to offer applications that have greater flexibility, agility, and speed. There are some essential strategies that need to be carried out by the development teams when it comes to testing microservices applications in order to deploy a secure application and some of those microservices testing strategies are discussed in this blog. These automated tests enable the developers to easily cater to customer requirements by offering a top-notch application.
